FEATURES Adjustable 3 speeds for Forward/Reverse mode. Use for heavy automotive and truck repair, construction or assembly line. Durable new twin hammer design creates more torque with less vibration.  Rear exhaust. SPECIFICATIONS MODEL ZIW611 DRIVE SQUARE 3/4" 19 mm FREE SPEED RPM 6,000 MAXIMUM TORQUE 1,100 ft.lbs 1492 Nm OPERATING AIR PRESSURE 90 psi 6.2 bar AVERAGE AIR CONSUMPTION 24.7 cfm 700 lm WEIGHT 10.45 lbs 4.75 kg MINIUM HOSE SIZE 3/8" 10 mm AIR INLET SIZE NPT 1/4"



DOWNLOADS AND VIDEOS [ZIW611 Parts Schematic]
